Carbon element
Knurled shaft - 18 teeth
Metal bushing
Metal shaft
Rear solder lugs
Operating Temperature ....... -10 °C to 70 °C
Power Rating...................... 0.25 watt
Maximum Operating Voltage ... 250 V
Rotational Noise .....................150 mV Max
| Manufacturer | Bourns |
| Length | 11.5 mm |
| Category | Passive Components |
| Diameter | 24 mm |
| Element Type | Carbon |
| Maximum Operating Temperature | 70 C |
| Minimum Operating Temperature | - 10 C |
| Mounting Style | Panel Mount |
| Number of Turns | 1 Turn |
| Power Rating | 250 mW (1/4 W) |
| Product | Guitar Potentiometers |
| Product Type | Potentiometers |
| Resistance | 250 kOhms |
| Shaft Diameter | 6 mm |
| Shaft Length | 19 mm |
| Shaft Type | Knurled / Serrated |
| Taper | Audio |
| Termination Style | Solder Lug |
| Tolerance | 20 % |
| Tradename | Pro Audio |
| Type | Rotary Metal |
| Voltage Rating | 250 V |
